·SSD、SDP型可伸缩带式输送机 Extensible Belt convey

SSD、SDP型可伸缩带式输送机 Extensible Belt conveyor

上下运可伸缩带式输送机Upwards and downwards Extensible Belt conveyor
型号规格 Model	运量 capa.	运距 Max length	带宽 Belt width	带速 Speed	倾角 Upper slope	电机功率 Power	传动滚筒直径 Drum Dia.	托辊直径 Roller Dia.	整机质量 Weight
型号规格 Model	t/h	m	mm	m/s	(°)	kw	mm	mm	t
SSJ650/40S	100	250	650	1.6	12	40	500	108	21.3
DTS80/12.5/55S	125	400	800	2	8	55	500	108	16.46
SSJ1000/320S	500	500	1000	2.5	16	2×160	800	108	75.42
DSP763/1000S	630	700	1000	2	18	2×125	630	108	74.95
SSJ100/160S	800	300	1000	2	10	160	630	108	75.42
DSJ100/80/200S	800	400	1000	2.5	3	200	800	108	50.95
DSP1080/2×200	800	1000	1000	2.5	7	2×200	630	108	93.71
SSJ1200/2×220S	1000	500	1200	2.5	12	2×200	800	133	97.88
DSJ120/150/2×220	1500	1000	1200	3.15	15	2×200	830	133	144.11
DTS80/12.5/40X	125	500	800	2	-12	40	500	108	20.84
DSJ80/20/160X	200	1500	800	2	-5	160	630	108	57.59
SSJ1000/2×160X	1000	1200	1000	2.5	-16	2×160	800	108	140.66
SSJ100/160X	1000	1200	1000	2.5	-10	160	800	108
双向可伸缩带式输送机 Extensible Belt conveyor
DSP1010/650A	100	1000	650	1.6		40	500	108	72.01
DSJ65/10/55	100	1000	650	1.6		55	500	108	60.47
SSD800/90U	150	1000	800	1.6	-10	90	630	108	109.88
DSJ80/20/2×55H	200	1500	800	2		2×55	500	108	111.34
SSJ800/2×40H	315	1000	800	2		2×40	500	108	92.86
SSJ800/90S	400	400	800	2	15	90	630	108	52.37
转弯可伸缩带式输送机 Curved Extensible Belt conveyor
SWJ800/90	400	1000	800	2	≤10	90	630	108	87.18
SWJ100/160	400	1600	1000	2.5	≤10	160	630	108	157.23
SWJ1000/160	630	1000	1000	2.5	≤10	160	630	108	102.91
DSJ100//63/125W	630	1000	1000	2	≤10	125	630	108	123.84
DSP1080/1000	800	700	1000	2.5	≤10	110	630	108	58.65
