该浮选机用于地质、冶金、建材、化工、煤炭、矿山选厂及院校科研单位试验室搅拌、分离、擦洗、精选矿样等。本产品由原地矿部唯一指定企业生产，执行行业标准。
The flotation machines are employed for agitation , separation, scrubbing and cleaning of samples in labs of geological, metallurgical, building material, chemical, coal, beneficiation plant of mine , institutions of higher learning and research institutions. The product is produced by the only manufacturer designated by the former. Ministry of Geology and Mineral Resources, in compliance with the Industrial standards.
XFG型挂槽浮选机XFG Model Hanging Cell Flotation Machine
XFG型挂槽浮选机用于搅拌、擦洗、分离和精选少量矿样等。该机具有浮选速度快和选别指标好等特点。
XFG Model Hanging Cell Flotation Machine is used for agitation separation, scrubbing and cleaning of minor samples with rapid speed of flotation and desirable separation indexes and other features.
| 型号规格 Model | 容量 Capa. | 选槽容积 Volume | 叶轮直径 Impeller diameter | 叶轮转速 Impeller speed | 给矿粒度 Feed size | 功率 Motor power | 质量 Weight |
| g | ML | mm | r/min | mm | w | kg | |
| XFG 5 | 5、15 25、35 | 20、60 100、140 | Φ20、Φ26、Φ30 | 1000-1850 | ≤0.2 | 90 | 15 |
| XFG 50 | 50、100 | 200 400 | Φ36、Φ48 | 1000-1850 | ≤0.2 | 90 | 16 |
| XFG 250 | 250、500 | 1000 2000 | Φ60、Φ64 | 1500、2000 | ≤0.2 | 250 | 25 |
| XFG | 1000 | 4000 | Φ80 | 900、1500 | ≤0.2 | 250 | 27 |
我们要求服务人员时刻关注客户，及时解决设备问题，确保顾客的利益比一切都重要。
