链篦机 Chain Grate
我厂生产的链篦机系链篦机-回转窑球团法球团生产工艺的专用履带式传热设备，其作用是将生球依次经过鼓风干燥段、抽风干燥段、预热Ⅰ段、预热Ⅱ段四个工艺段，从而完成脱水、预热、氧化作用，达到满足入回转窑的生球强度的要求，经铲料板铲下送入回转窑中。
The chain grates manufactured by our factory are special crawler-type heat-transfer equipment employing pelletizing technique of grate-kiln pelletizing method. Their functions are to get fresh pallet through four processes, namely air blowing drying section, down-draft drying section, preheating section I, and preheating section II, so as to finish dewatering, preheating, and oxidation as well as meet the requirements of green pellet strength entering rotary kiln. The pallets are transferred to the rotary kiln through the spading plate.
技术参数
| 规格 | 60万吨/年 | 120万吨/年 | 200万吨/年 | 240万吨/年 | 300万吨/年 | 500万吨/年 | |
| 2.8×36 | 4×36 | 4.5×50 | 4.5×60 | 5.4×59 | 5.8×78 | ||
| 篦床宽度 | m | 2.8 | 4.0 | 4.5 | 4.5 | 5.4 | 5.8 |
| 有效长度 | m | 36 | 36 | 50 | 60 | 59 | 78 |
| 有效面积 | ㎡ | 100.8 | 144 | 225 | 270 | 318.6 | 452.4 |
| 处理物料 | 生球 | ||||||
| 粒度 | ㎜ | 9～16 | 9～16 | 9～16 | 9～16 | 9～16 | 9～18 |
| 堆积密度/ | t/ m³ | 2.1 | |||||
| 生产能力/ | t/h | 90 | 220 | 350 | 340 | 450 | 730 |
| 料层厚度 | ㎜ | 160-180 | 200 | 220 | 200 | 220 | 200-220 |
| 头尾轮中心距 | ㎜ | 41075 | 39300 | 53300 | 63300 | 73300 | 83800 |
| 正常机速/ | m/min | 1.5 | 1.88 | 2.74 | 3 | 2.939 | 4.6 |
| 调速范围 | m/min | 0.57～2.9 | 0.93～2.77 | 1.14～3.42 | 1.25～3.75 | 1.3～3.9 | 2～5.6 |
| 物料停留时间 | min | 24 | 19.15 | 18.25 | 19.15 | 20.07 | 18.25 |
| 设备重量 | t | 471 | 766 | 1043 | 1250 | 1662 | 2125 |
注：表格参数仅供选型参考
